The LP brochure provides an overview of the LP-series filter units designed for low-pressure applications such as diesel engines, gear boxes, and lube oil systems, operating at less than 116 psi/8 bar.
The LP brochure provides an overview of the LP-series filter units designed for marine low-pressure applications such as diesel engines, gear boxes, and lube oil systems, operating at less than 116 psi/8 bar.
The HP brochure provides an overview of the HP-series filter units designed for high-pressure applications such as hydraulics, water-glycol systems, and transmissions, operating up to 4,567 psi/315 bar.
The HP brochure provides an overview of the HP-series filter units designed for marine high-pressure applications such as hydraulics, water-glycol systems, and transmissions, operating up to 4,567 psi/315 bar.
Written for Modern Contract Solutions Magazine in 2014, this article provides a overview of bypass oil filtration and how it differs from conventional full-flow oil filters (Author: Bill Butler, B.A., B.Sc., President, Oil Filtration Solutions Ltd.)
This article explains the importance of clean oil and how dirty oil negatively affects the health and life of machinery over time (Mike Sondalini & Don Irvine, Lubrication & Fluid Power, January-February, 2004)
ISO codes are a unit of measuring the cleanliness of hydraulic and other non-combustion oils. This document illustrates how an ISO code is assigned to a sample once a particle count is obtained by the spectrometer in the lab, based on the volume of dirt it counts in 3 different size categories contained in 1 ml of fluid.
Rates of mechanical wear are affected by oil pressure and the volume and size of particulate it contains. Some components with fine tolerances such as servo valves, require super clean oil to function properly. The type of component and the operating pressure of the oil, will determine how clean the oil should be to minimize mechanical wear and maximize the life of the equipment.
The volume of dirt in non-combustion oils such as hydraulic oil is measured and assigned a cleanliness code. In 1964 the NAS scale was created and counted 5 different categories of particle sizes per 100 ml of fluid. The NAS method has since been replaced by ISO. Since 1991 the International Standards Organization (ISO) 4406, assigns a 3 digit code, by counting the number of particles >4, >6, >14 microns in size per 1 ml of fluid, providing a much more concise measurement of solid contamination. For example, new unused hydraulic oil should not contain more than 10,000 particles 4 microns in size or greater, per 1 ml of oil. Once you test your oil, you can see where it falls on the cleanliness scale.
The presence of sub-micron metals helps identify the source of mechanical wear. Oil from a variety of components on mobile equipment can be tested to detect premature wear and problems before a failure takes place.
An overview of the various tests laboratories perform on diesel engine oil. Regular testing of engine oil will detect potential engine problems in their infancy stages, and help identify the cause and source of the issue should one exist.
